7-Ton naik-on listrik forklift seri G2 CPD 7.0T

7-Ton naik-on listrik forklift seri G2 CPD 7.0T

Forklift listrik tumpangan BYD CPD 7.0T, cocok untuk kondisi kerja tugas berat 7 ton, menggunakan penggerak baterai lithium, kebisingan rendah dan operasi hemat energi, cocok untuk pergudangan, manufaktur, bahan bangunan
Kirim pertanyaan
Detail produk

    BYD CPD 7.0T naik forklift listrik,
Cocok untuk kondisi tugas berat 7 ton
Peralatan penanganan energi baru. Mengandalkan teknologi baterai lithium yang matang dan proses pembuatan Seiko, peralatan berjalan lancar, memiliki kontrol yang fleksibel, kebisingan rendah, dan penghematan energi.
Kinerja efisiensi dan keselamatan operasional yang seimbang
Ini dapat disesuaikan dengan berbagai lingkungan operasi yang kompleks, menyediakan pilihan yang cocok untuk transportasi bahan berat di perusahaan.

    Kendaraan mengadopsi skema penggerak listrik murni, dengan output daya yang stabil dan respons cepat terhadap tindakan mengemudi dan mengangkat.
Membantu meningkatkan efisiensi kerja
. Performa traksi dan pendakian cocok untuk kondisi jalan seperti landai dan perbedaan ketinggian permukaan jalan di area pabrik, dan transfer pabrik luar ruangan dan operasi gudang dalam ruangan dapat beroperasi dengan stabil. Dilengkapi dengan baterai daya berkapasitas besar,
Mendukung operasi berkelanjutan jangka panjang
Untuk memenuhi permintaan penanganan barang curah secara terus menerus.

     Kendaraan mengadopsi sistem kontrol elektronik AC dengan struktur pengereman hidrolik, yang memiliki pengereman sensitif dan pengoperasian sistem hidrolik yang stabil. Kontrol kebisingan di area kerja masuk akal, lingkungan mengemudi nyaman, dan cocok untuk skenario operasi jangka panjang. Struktur bodi kokoh, dan daya dukung beban disesuaikan dengan permintaan beban berat. Dengan ban pneumatik dan ground clearance yang wajar, daya pasnya bagus, yang dapat mengurangi dampak rintangan jalan.

     Kendaraan ini memiliki kemudi yang fleksibel dan desain radius belok yang wajar. Di gudang dengan rak padat dan bengkel dengan lorong kompak, kemudi, penyelarasan, susun dan operasi lainnya dapat berhasil diselesaikan, dan cocok untuk palet arus utama dan lorong penyimpanan. Gantry berjalan lancar, kinerja penahan beban garpu stabil, dan operasi pengangkat, bongkar muat dan susun kargo berat dapat diselesaikan dengan lancar.

     Forklift ini cocok untuk berbagai skenario: pabrik dapat digunakan untuk transfer lintas bengkel bahan baku berat dan benda kerja jadi skala besar dan alokasi stasiun; pusat pergudangan besar, taman logistik dan galangan barang, cocok untuk seluruh palet dan barang berat di dalam dan di luar penyimpanan, penumpukan, bongkar muat dan pergantian jarak pendek; pada saat yang sama, sangat cocok untuk pengolahan logam, bahan bangunan, pakan, rantai dingin dan industri lainnya untuk memenuhi kebutuhan penanganan bahan berat seperti baja, bahan bangunan, barang curah, dan barang rantai dingin.

    Forklift listrik BYD CPD 7.0T mengintegrasikan karakteristik kapasitas tugas berat, operasi yang efisien, hemat energi dan perlindungan lingkungan, keamanan dan daya tahan, dll. Ini memiliki biaya operasi yang ekonomis dan perawatan yang nyaman.
Membantu perusahaan meningkatkan efisiensi penanganan material
Ini memberikan solusi peralatan yang cocok untuk skenario penanganan tugas berat multi-industri.

nama parameter
satuan
CPD sentire7.0T
produsen
-Rumah
Model
-CPD sentire7.0T
mengemudi
-listrik
Bentuk manipulasi
-Mobil-mount
kapasitas beban
kg
7000
pusat beban
mm
600
overhang
mm
675
basis roda
mm
2280
Berat kotor (termasuk baterai)
kg
12500
Beban gandar depan / belakang, beban
kg
16740/2760
Beban gandar depan / belakang, tanpa beban
kg
5820/6680
Kategori roda
-ban tiup
Ukuran roda depan
mm
8.25-15
Ukuran roda belakang
mm
250-15
Jumlah roda depan / belakang x = roda penggerak
-4x / 2
jalur depan
mm
1541
jalur belakang
mm
1450
Sudut Depan / Belakang
gelar
6-10
Tinggi gantry minimum
mm
2770
Tinggi angkat gratis
mm
170
mengangkat tinggi
mm
3300
Tinggi maksimum gantry (dari tanah)
mm
4770
Tinggi langit-langit
mm
2780
Tinggi kursi (dari tanah)
mm
1708
Tinggi pin traksi
mm
570
panjang penuh
mm
4770
Panjang penuh (tidak termasuk garpu)
mm
3550
lebar total
mm
2076
Ukuran garpu
mm
75/150/1220
Rak garpu yang sesuai dengan ISO 2328, bingkai / bentuk A, B
-4A
margin pagar pembatas
mm
1800
Tinggi minimum dari tanah di gantry
mm
200
Tinggi minimum dari tanah di bingkai
mm
200
Lebar saluran dengan baki horizontal 1000x1200
mm
5355
Lebar saluran dengan baki vertikal 800x1200
mm
5555
radius putar minimum
mm
3260
Radius belok ke dalam
mm
1250
Kecepatan mengemudi, beban / tanpa beban
Km / jam
16/17
Kecepatan angkat, beban / tanpa beban
mm / s
350/400
Jatuhkan kecepatan, muat / tanpa beban
mm / s
500/400
Traksi maksimum S2 = beban 5 menit / tanpa beban
KN
32/28
Kapasitas pendakian maksimum S2 = beban 5 menit / tanpa beban
%15/20
Waktu akselerasi, beban / tanpa beban (0-10m)
s
-
Bentuk rem
-hidrolik
Kekuatan motor penggerak S2 = 60min
kW
182
Mengangkat daya motor S3 = 15% ED
kW
242
Kapasitas baterai
V / Ah
80/840
Berat baterai
kg
1200
Jenis kontrol elektronik
-AC
Tekanan kerja sistem hidrolik
Mpa
Tidak lebih dari 18.
Kebisingan dari pengemudi
dB (A)
Tidak lebih dari 80.
